LENOVO ThinkSystem ST250 V2 1x Xeon E-2378G 8C 2.8GHz 80W 1x16GB 2Rx8 SW RD 1x550W

Lenovo ThinkSystem ST250 V2: High-Performance, Flexible Tower Server for Growing Businesses

The Lenovo ThinkSystem ST250 V2, available at 7stores.au, is a powerful 1-socket tower server that offers the versatility to be rack-mounted, making it ideal for small-to-medium businesses, remote offices, branch offices, and sectors like banking and public services. Engineered with enterprise-class power and scalability, this server is built to meet the evolving needs of your growing business, providing the perfect balance of performance, flexibility, and manageability.

Exceptional Performance with Intel Xeon E-2378G Processor

At the core of the ThinkSystem ST250 V2 is the Intel Xeon E-2378G processor—a high-performance octa-core (8-core) CPU that operates at a base clock speed of 2.8 GHz with a 16 MB cache. This processor is part of the latest Intel Xeon E-2300 Series (formerly "Rocket Lake"), delivering up to a 17% performance improvement over previous generations. With a TDP of 80W, it provides robust processing power while maintaining energy efficiency, making it ideal for demanding workloads such as IT infrastructure management, near-side data backup, and edge computing.

Flexible Memory and Extensive Storage Options

The Lenovo ThinkSystem ST250 V2 is equipped with 16GB of TruDDR4 ECC memory (2Rx8) and supports up to 128GB of 3200 MHz TruDDR4 ECC memory across four DIMM slots. This ensures high data integrity and seamless performance for a wide range of applications.

In terms of storage, the ST250 V2 offers exceptional flexibility with multiple configuration options:

• Up to 16x 2.5-inch hot-swap SAS/SATA drives for performance-optimized setups
• Up to 8x 3.5-inch hot-swap SATA drives for capacity-focused needs
• Hybrid configurations that combine 4x 3.5-inch and 8x 2.5-inch hot-swap drives
• Two internal M.2 modules for efficient booting and system operation

These options allow you to tailor the server’s storage capabilities to meet your specific needs, whether you prioritize speed, capacity, or redundancy. Additionally, the server supports various RAID options, ensuring data protection and reliability.

Expandability and Connectivity for Future Growth

The ThinkSystem ST250 V2 is designed to grow with your business. It features four PCIe expansion slots:

• 1x PCIe Gen4 x16 slot for high-performance GPU or I/O cards
• 3x PCIe Gen3 slots (x4 lanes) for additional I/O expansion

This expandability ensures that your server can adapt to evolving business requirements, making it a future-proof investment.

The server is also equipped with dual integrated Gigabit Ethernet ports (Broadcom BCM5720) and an additional 1 GbE port dedicated to Lenovo XClarity Controller (XCC) management, providing reliable and scalable network connectivity.

Enterprise-Level Manageability and Security

The Lenovo ThinkSystem ST250 V2 comes with Lenovo XClarity Controller Enterprise, a powerful tool that simplifies server management and reduces provisioning time. This system allows you to manage your IT infrastructure with ease, even from remote locations, thanks to the XClarity Mobile app.

Security is a top priority, with features including Intel® SGX (Software Guard Extensions) for securing sensitive application code and data, TPM 2.0 for hardware-based security, and an optional lockable front bezel and chassis intrusion switch to protect against unauthorized access.

Energy-Efficient Design for Remote Office Use

The ST250 V2 is engineered for environments with minimal IT support, such as remote offices or branch locations. Its compact footprint and office-quiet cooling system make it ideal for deployment in space-constrained settings. The server also features dual 550W hot-swap power supplies for redundancy, ensuring continuous operation even in the event of a power failure.

Operating System Compatibility

The ThinkSystem ST250 V2 supports a wide range of operating systems, including:

• Microsoft Windows Server 2022
• Red Hat Enterprise Linux (versions 8.4, 8.7, 8.8, 9.0, 9.1, 9.2)
• SUSE Linux Enterprise Server (15 SP3, 15 SP4)
• VMware vSphere

This broad compatibility ensures seamless integration into your existing IT environment.

Detailed Specifications

• Form Factor: 4U tower chassis; Height: 430mm (16.9 inches), Width: 175mm (6.9 inches), Depth: 566mm (22.3 inches)
• Processor: 1x Intel® Xeon® E-2378G, 8 cores, 2.8 GHz, 16 MB cache, 80W
• Memory: 16GB TruDDR4 ECC (2Rx8), supports up to 128GB in 4x DIMM slots
• Storage Options:
  • 8x 3.5-inch simple-swap SATA drives
  • 16x 2.5-inch hot-swap SAS/SATA drives
  • Hybrid 4x 3.5-inch hot-swap + 8x 2.5-inch hot-swap SAS/SATA drives
  • Optional M.2 mirroring kit (supports 2x SATA M.2 drives; installs in PCIe slot)
• Expansion Slots:
  • 1x PCIe Gen4 x16 slot
  • 3x PCIe Gen3 x4 slots
• Network Interface:
  • 2x GbE on-board ports (Broadcom BCM5720)
  • 1x GbE port dedicated for XCC management
• Ports:
  • Front: 1x USB 3.2 G2 (10Gbps), 1x USB 2.0 for local management using XCC Mobile app
  • Rear: 4x USB 3.2 G2 (10Gbps), 2x RJ45 Gigabit Ethernet ports, 1x Serial port, 1x VGA port
• Security Features:
  • Embedded TPM 2.0
  • Intel® SGX
  • Optional lockable front bezel, chassis intrusion switch
• Power Supply: Dual 550W hot-swap power supplies
• Weight: Approx. 23.60 kg
• Operating System Support: Microsoft Windows Server 2022, Red Hat, SUSE, VMware vSphere

Why Choose the Lenovo ThinkSystem ST250 V2?

The Lenovo ThinkSystem ST250 V2, available at 7stores.au, is the perfect solution for businesses seeking a powerful, flexible, and scalable server that can be deployed in a tower or rack configuration. With its high-performance Intel Xeon E-2378G processor, robust memory and storage options, and advanced management features, this server is designed to meet the needs of growing businesses while providing room for future expansion.

Choose the Lenovo ThinkSystem ST250 V2 to empower your business with enterprise-level performance, security, and manageability.
