Lenovo ThinkSystem SR630 V3 1x Intel Xeon Silver 4514Y 16C 150W 2.0GHz 1x16GB 2Rx8 ThinkSystem RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter 1x750W XCC2 Std | 3-year warranty | Now available at 7Stores.au | 7D73A04KAU

Lenovo ThinkSystem SR630 V3 - High-Performance 1U Rack Server for Enterprise Workloads

The Lenovo ThinkSystem SR630 V3, available at 7stores.au, is a powerful and versatile 2-socket 1U rack server designed to meet the needs of businesses of all sizes, from small enterprises to large organizations. This server is engineered to deliver industry-leading reliability, advanced management, and robust security, making it an ideal choice for a wide range of demanding workloads, including databases, virtualization, cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web hosting, and high-performance computing (HPC).

Powered by Intel Xeon Silver 4514Y Processor

At the core of the ThinkSystem SR630 V3 is the Intel Xeon Silver 4514Y processor, a 16-core CPU with a base clock speed of 2.0 GHz and 30 MB cache, operating with a 150W TDP. This fourth-generation Intel Xeon Scalable processor delivers the computational power necessary for handling the most demanding enterprise applications, ensuring consistent and reliable performance across multiple workloads.

Scalable Memory and Advanced Storage Options

This configuration includes 32GB of TruDDR5 ECC memory (2Rx8), with the capability to expand up to a massive 8TB across 32 DIMM slots. The server also supports RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter, ensuring high data reliability and fault tolerance, crucial for data-intensive tasks and applications.

Key features include:

• Up to 10x 2.5-inch hot-swap drive bays for versatile and expandable storage configurations.
• Support for multiple RAID levels (0, 1, 5, 6, 10, 50, 60) to enhance data protection and performance.
• PCIe Gen4 slots for faster data transfer and improved overall system performance.

Robust Security and Management

The ThinkSystem SR630 V3 is equipped with Lenovo XClarity Controller (XCC) Standard for embedded management and Lenovo XClarity Administrator for centralized infrastructure management. These tools provide a streamlined hardware provisioning and maintenance experience, supported by Redfish-compliant REST APIs that enable a data-driven, centralized view of data center operations.

Lenovo ThinkShield security features ensure that your server is protected throughout its lifecycle. Key security features include:

• Chassis intrusion switch
• Power-on and Administrator passwords
• Root of Trust module supporting TPM 2.0
• Platform Firmware Resiliency (PFR)
• Hot-Swap/Redundant Power Supplies

These features make the ThinkSystem SR630 V3 a secure and reliable solution for enterprises seeking to protect their data and infrastructure.

Energy-Efficient Power Supply and Versatile Networking

The ThinkSystem SR630 V3 comes with a 750W 80 PLUS Platinum hot-swap power supply, designed to provide reliable power while minimizing energy consumption. This energy-efficient power supply ensures the server operates efficiently, reducing overall operational costs.

For networking, the server includes:

• 4x RJ-45 network ports for robust network connectivity
• Multiple USB and VGA ports for flexible connectivity
• Redundant power supplies to ensure continuous operation in the event of a power supply failure

Detailed Specifications

• Form Factor: 1U rack server
• Processor: 1x Intel® Xeon® Silver 4514Y, 16 cores, 2.0 GHz, 30 MB cache, 150W TDP (supports up to 2 processors)
• Memory: 32GB TruDDR5 ECC (2Rx8), supports up to 8TB across 32 DDR4 DIMM slots
• Storage: Up to 10x 2.5-inch hot-swap drive bays; RAID 940-8i 4GB Flash PCIe Gen4 12Gb Adapter
• Expansion Slots: 2x PCIe Gen4 slots
• Security Features: Lenovo ThinkShield, Chassis Intrusion Switch, TPM 2.0, PFR, hot-swap/redundant power supplies
• Power Supply: 750W 80 PLUS Platinum hot-swap power supply
• Networking: 4x RJ-45 network ports, OCP 3.0 slot for flexible networking options
• Management: Lenovo XClarity Controller, Lenovo XClarity Administrator
• Operating System Support: Microsoft Windows Server, SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Ubuntu, VMware vSphere

Why Choose the Lenovo ThinkSystem SR630 V3?

The Lenovo ThinkSystem SR630 V3, available at 7stores.au, is the perfect solution for businesses that require a powerful, scalable, and secure server for their data center. With its robust Intel Xeon Silver 4514Y processor, extensive memory and storage capabilities, and advanced management and security features, the SR630 V3 is designed to meet the demanding needs of modern enterprise workloads.

Equip your business with the Lenovo ThinkSystem SR630 V3 and ensure your infrastructure is optimized for future growth and reliability.
